Key Specifications
Important product information and key features.
Brand
S-Power
Model
Diamond Pro 3-YS3576
Screen Size
86" Inch
Light source
DLED
Display
86" Inch,16:9 Visual Ratio,IPS/VA,60Hz,1.07B (10bit) Colors,72% Color saturability,5000:1 Contrast ratio,178°(H/V) Viewing Angle,Up to 500 cd/m2 Brightness,8ms Response Time,60Hz
Max Visual Area
1895.04 x 1065.96 mm, Inches: ~74.61 in (Horizontal) × ~41.97 in (Vertical)
Resolution
3840 (H) x2160 (V)
Pixel Pitch
0.4296×0.4296mm
Cabinet Color
Black / Starry Gray
Processor (CPU)
4*A72+4*A53 (Octa Core 2.2 Ghz Processor)
Graphics (GPU)
G52 MC3
Memory (RAM)
16GB RAM
Storage (ROM)
256 GB Storage
Touch Points
50 Touch
Touch Accuracy/Min.Identifier
± 1 mm,1mm
Input Mode
Opaque object (finger,Pen,etc)
Response Time
4ms
Touch Depth/Writing Height
±1mm /( ≥ 2mm)
Writing Display
Single Stylus Pen two-colour
Output coordinates
32767 (W) x32767(D)
Speakers
2 x 20 Watt(65" & 75") & 2 x 25 Watt (86" & 98"),25 Watt Woofer(Optional)
Wireless & Communication
Dual-band Wi-Fi module supporting 2.4 GHz and 5 GHz networks (802.11 b/g/n/ac) + Bluetooth 5.2 or above,0-10m Working Distance
Standard Ports
I/O Interface, 1 x RS232, 1 x MIC IN, 1 x COAX, 1 x Line Out /LAN Out, 1 x LAN IN, 2 x Touch USB 2.0, 2 x (ARC*l) HDMI In/HDMI Out, 1 x DP In, 1 x TYPE-C In/Out, 1 x USB 3.0 (Public), 1 x USB 3.2 (Android), 1 x USB OTG /TF CARD, Front Interface, 2 x USB 3.0 (Front), 1 x (HDMI 2.0) HDMI In, 1 x Type-C
Bare Dimension
Approx.1950 x 1159mm
Machine+wall mount thickness
118mm
VESA hole site
800 x 400mm
Wall Mounting Screw Specifications
M8x25m m
Environment
Working temperature : 0 °C–40°C, Working Humidity : 10%~90%RH, Storage temperature : -20°C~60°C, Storage Humidity : 10%~90%R, Working Elevation : <5000m
Max. power consumption
350w
Standby power consumption
≤ 0.5W
Viewing Angle
178° Wide Viewing Angle
Touch Technology
Infrared (IR) Touch
Camera
Built-in 48 MP 4K AI Camera (120° FOV, Auto-framing, and Speaker Tracking)
Microphone
Integrated 8-Array Microphone System (AI Noise Reduction, 10m pickup)
Net Weight
Approx. 55 KG
System Version
Android 15.0
Operating System
Windows 10/Windows8/Wmdows7 /Wmdows XP/Android/Linux/Mac OS X/Chrome
Life Span
Up to 10000 Hrs (Depends On Uses)
Accessories
1 x Powercord, 1 x Stylus Pen, 1 x Wall Mount, 1 x Operation manual
Use Case
AI-powered Education, High-end Corporate Collaboration, and 8K Content Display
Warranty
1 Year Manufacturer Warranty
Made In
Turkey
Service
S-Power
